YESAIR Incubator Verification Monitor

Category : Indoor Air Quality Monitors

Kondisi : NEW

View : 129

ORDER NOW !!

Hotline 1 : 0822-5102-2483

Hotline 2 : 0857-7556-1612 (Marketing Team)

Hotline 3 : 0812-8847-8408

Description
Specification

Handheld IAQ monitor and data logging instrument, designed for accurate monitoring of CO2, O2, temperature and RH in incubators.
The YESAIR Incubator Verification monitor is a handheld gas monitor that provides a quick, easy and accurate way to monitor carbon dioxide, oxygen, temperature and relative humidity in incubators used in biomedical research facilities, IVF facilities, laboratories, poultry farms and other medical applications.
The YESAIR uses a remote sample probe that enters through the port on the door or side of the incubator and provides a direct reading of the CO2 (and O2 if installed) levels inside the chamber. Coupled with our 3-point calibration standard, and the use of an infrared sensor, the CO2 sensor offers stable and accurate measurement readings of the CO2 levels.
Incubators are maintained at fairly high temperatures and are required to sustain a high relative humidity. The YESAIR has built in sensors at the tip of the secondary probe to sample temperature and RH to confirm the internal chamber readings.
Includes monitor with pump, remote sampling probe to measure target gas, remote sampling probe to measure temperature and RH, calibration tubing, three “AA” NiMH rechargeable batteries, AC adapter and battery charger in a hard plastic carrying case. The optional YES Logger package is available with 2GB memory card, card reader, USB cable and YES Viewer Software.

Key Features

Stable infrared CO2 sensor technology, available with O2 sensor also

Remote sample probes for easy entry into incubator port

Large graphic LCD display with a multi-function, easy to use menu

Light weight, contoured & comfortable to hold

Comes with rechargeable batteries and AC adapter/charger

Optional high capacity data logging with 2GB SD memory card and software for collecting, analyzing and graphing data

RoHS compliant circuit boards

CE certified

Specifications

Target

Gas Sensors

Carbon dioxide (CO2), Oxygen (O2)

Other Sensors

Temperature and RH

Mechanical

Enclosure

Rugged ABS / Polycarbonate (UL94 rated)

Weight

567 g / 20 oz

Size

197 x 78 x 98 mm / 7.8 x 3.1 x 3.9 inches

Case (included)

Hard plastic storage/carrying case with foam lining

User Interface

Display

Back-lit, multi-line LCD alphanumeric display

Buttons

3 tactile push buttons for user access

Calibration

Automated through keypad

Audible Alarm

Internal 80 dB @ 4’. One set point adjustment. Audible can be switched off through menu

Data Logging

Sampling Mode

Internal sample pump automatically draws in gas sample of target environment, particulates are sampled by diffusion

Memory

> 1 million data points data logging to SD flash card (optional)

Recording

12 bit, multi-channel, user configurable with 2GB SD memory card slot

Optional: YES Logger package with 2GB SD memory card, card reader, USB cable and YES Viewer Software

Communication

Miniature USB port for changing settings and configuring logging functions

Auxiliary port for attaching the particulate sensor

Electrical

Power

Rechargable 3.6 V NiMH battery pack with plug-in battery charger 100 - 240 V, 50-60 Hz

Continuous operation with plug-in wall adapter 6VDC, Class-III, 2 A DC max

Optional: Alkaline AA batteries x 3

Environmental

Operating Temperature

5°C to 50°C (41°F to 122°F)

Storage Temperature

-20°C to 60°C (-4°F to 140°F)

Operating Humidity

0 - 99% RH non-condensing

Certifications

Conforms to

CE standards for safety: I.S. EN61010-1:2001 (Ed.2)

CE standards for emissions: EN 50270:2006

CE standards for immunity: EN 50270:2006

RoHS compliant circuit boards

UL94 flammability rating
